119.The structure that the arrow labeled “A” is pointing to is the
a. Stomach
b. Liver
c. Ascending colon
d. Gall bladder
D Gall bladder
120. The structure that the arrow labeled “A” is pointing to is the
a. Spinal column
b. Kidney
c. Gall bladder
d. Psoas muscle
D Psoas muscle
121. The arrow labeled “A” is pointing to is the
a. Glenoid process
b. Corocoid process
c. Superior glenoid labrum
d. Inferior glenoid labrum
A Glenoid process
122. The arrow labeled “c” is pointing to is the
a. Inferior spinatous muscle
b. Supraspinatous muscle
c. Teres Major muscle
d. Deltoid Muscle
D Deltoid Muscle
123. The structure that the arrow labeled “B” is pointing to is the
a. Glenoid process
b. Corocoid process
c. Superior glenoid labrum
d. Inferior glenoid labrum
D Inferior glenoid labrum
124. The structure that the arrow labeled “A” is pointing to is the
a. Spine
b. Esophagus
c. Trachea
d. Spinal cord
B Esophagus
125. The structure that the arrow labeled “B” is pointing to is the
a. Spine
b. Esophagus
c. Trachea
d. Spinal cord
C Trachea
126. The arrow labeled “8” is pointing to is the
a. Lateral miniscus
b. Fibula
c. Episipheal plate
d Distal femur
C Episipheal plate
127. The arrow labeled “A” is pointing to is the
a.Posterior longitudinal ligament
b.Cauda equina
c.Ligament flavum
d.Conus
D Conus
128. The arrow labeled “B” is pointing to is the
a. Posterior longitudinal ligament
b. Cauda equina
c. Ligament flavum
d. Conus
B Cauda equina
129. The arrow labeled “A” is pointing to is the
a. Subarachnoid space
b. Cauda equana
c. Thecal sec
d. Conus
A Subarachnoid space
130. The arrow labeled “B” is pointing to is the
a. Thecal sac
b. Cauda equana
c. Lamina
d. Psoas muscle
B Psoas muscle
131. The arrow labeled “C” is pointing to is the
a. Thecal sac
b. Cauda equana
c. Lamina
d. Conus
C Lamina
132.The arrow labeled “D” is pointing to is the
a. Thecal sac
b. Spinous process
c. Lamina
d. Conus
B Spinous process
133. The structure that the arrow labeled “A” is pointing to is the
a. Mandibular condyle
b. Articular disc
c. Carotid artery
d. Lamina
B Articular disc
134. The arrow labeled “B” is pointing to is the
a. Mandibular condyle
b. Mandibular fossa
c. Carotid artery
d. Lamina
A Mandibular condyle
135. The arrow labeled “A” is pointing to is the
a. Thalmus
b. Basal Ganglia
c. Genu of the corpus collosum
d. Head of the caudate nucleus
D Head of the caudate nucleus
136. The structure labeled “A” is composed of
a. Grey matter
b. White matter
c. Both a and b
d. None of the above
A Grey matter
137. The structure that the arrow labeled “B” is pointing to is the
a. Thalmus
b. Basal Ganglia
c. Lateral Ventricle
d. Head of the caudate nucleus
A Thalmus
138. The arrow labeled “2” is pointing to is the
a. Anterior cerebral artery
b. Posterior cerebral artery
c. Right middle cerebral artery
d. Left middle cerebral artery
C Right middle cerebral artery
139. The structure that the arrow labeled “A” is pointing to is the
a. Common iliac artery
b. Femoral artery
c. Right external iliac artery
d. Right internal iliac artery
C Right external iliac artery
140. The structure that the arrow labeled “B” is pointing to is the
a. Common iliac artery
b. Femoral artery
c. Right external iliac artery
d. Left internal iliac artery
D Left internal iliac artery
141 The arrow labeled “A” is pointing to is the
a. Grey Matter
b. White Matter
c. Thalmus
d. Choroid plexus
A Grey Matter
142. The arrow labeled “B” is pointing to is the
a. Grey Matter
b. White Matter
c. Thalmus
d. Choroid plexus
B White Matter
143. This image was likely acquired in the
a. Axial plane
b. Coronal plane
c. Sagittal plane
d. Oblique plane
A Axial plane
144. This image was most likely acquired with a
a. Short TR and a short TE
b. Short TR and a long TE
c. Long TR and a long TE
d. Long TR and a short TE
D Long TR and a short TE
145. The arrow labeled “A” is pointing to is the
a. The lateral meniscus
b. The medial meniscus
c. The posterior cruciate ligament
d. The anterior cruciate ligament
C The posterior cruciate ligament
146. The structure that the arrow labeled “A” is pointing to is the
a. Uterus
b. Pubic Symphysis
c. Bladder
d. Rectum
A Uterus
147. The arrow labeled “B” is pointing to is the
a. Uterus
b. Pubic Symphysis
c. Bladder
d. Rectum
B Pubic Symphysis
148. The arrow labeled “C” is pointing to is the
a. Uterus
b. Pubic Symphysis
c. Bladder
d. Rectum
C Bladder
149. The structure labeled as “D” is pointing to is the
a. Body of the uterus
b. Vagina
c. Prostate gland
d. Cervix of the uterus
D Cervix of the uterus
150. The structure labeled as “E” is pointing to is the
a. Myometrium
b. Vagina
c. Uterine cavity/Endometrium
d. Cervix of the uterus
C Uterine cavity/Endometrium
151. The structure that the arrow labeled “A” is pointing to is the
a. Superior labrum
b. Inferior labrum
c. Posterior labrum
d. Anterior labrum
C Posterior labrum
152. The arrow labeled “B” is pointing to is the
a. Superior labrum
b. Inferior labrum
c. Posterior labrum
d. Anterior labrum
D Anterior labrum
153-160 Name A through H
A Triangular fibrocartilage complex, B
Lunate bone, C Triquetral bone, D
Hammate bone, E Capitate bone, F
Trapezoid, G Trapezium, H Scaphoid
161. The structure that the arrow labeled “A” is pointing to is the
a. Choroid pleuxus
b. Anterior horn of the lateral ventricle
c. Cerebral Aqueduct
d. Aqueduct of Sylvius
A Choroid pleuxus
162. The arrow labeled “A” is pointing to is the
a. Parietal lobe
b. Cerebellum
c. Sylvian fissure
d. Falx Cerebri
C Sylvian fissure
163. The arrow labeled “A” is pointing to is the
a. Ethmoid sinuses
b. Maxillary sinuses
c. Frontal Sinuses
d. Naso-pharynx
B Maxillary sinuses
164. The structure that “A” is pointing to is the
a. Cerebral Aqueduct
b. Thalmus
c. Pons
d. Mid brain
A Cerebral Aqueduct
165. The structure that “B” is pointing to is the
a. Pons
b. Midbrain
c. Thalmus
d. Corpus collusum
